14.4V Mechanical Pulse Tool Wrench EYFMA2C / EYFMA2P / EYFMA2CR / EYFMA2PR

14.4V Mechanical Pulse Tool Wrench EYFMA2C / EYFMA2P / EYFMA2CR / EYFMA2PR

Models EYFMA2C / EYFMA2P EYFMA2CR / EYFMA2PR
Voltage 14.4V
Series AccuPulse - HR Series AccuPulse - HR Series with 2-Way Communication
Drive C = 1/2” Sq. C-Ring w/ through Hole P = 1/2” Sq. Pin Detent
Torque Range Nm 25-120Nm
ft. lbs. 18.44-92.2 ft. lbs
in. lbs. 221.27-1,106.34 in. lbs.
Max Torque* (F mode, tightening 3 sec.) 185Nm M16 Bolt 185Nm M14 Bolt
Flush Detection Modes L1 - L7
No Load Speed (Torque Setting: RPM) 1-40 & F: 0-2300
PPM (Pulses Per Min) 1-40 & F: 0-2900
Weight 1,40 kg (incl. 2.0 Ah (EYFB41B))
1,60 kg (incl. 4.2 Ah (EYFB42B))		 1,40 kg (incl. 2.0 Ah (EYFB32B))
1,60 kg (incl. 4.2 Ah (EYFB30B))
Size (L x W x H) 153mmx59mmx231mm (EYFB32)
153mmx59mmx249mm (EYFB30)
Wireless Communication
with Assembly Qualifier:		 — X
LED Work Light: (ON/OFF Switch) X
OK/NOK Light: (Green: OK / Red: NOK) X
Rehit Prevention: (Possible to set per 0.1 sec. between 0-3 sec.) X
Battery Indication Lamp: (3 stage) X
Low Power Disable X
Prevent / Detect Cross Threads & Rehits X
Maintenance Interval Alarm X
Variable Speed On / Off Switch X
Variable Speed On / Off Switch X
Buzzer: On / Off X
Flush Point Detection Delay (Possible to
set between 0-3 sec.. 0.1 sec. per stage)		 X
Socket Extension Mode
(h1:150mm socket, h2: for 250mm socket)		 X
Work Capacity / Fastening Speed* <M12: 71 N·m, Stage: 22>
(EYFB42B) 600 pcs/pack, 0.8 sec/1pcs
(EYFB41B) 270 pcs/pack, 0.8 sec/1pcs
Charging Time* (Battery Pack EYFB41, Charger EY0L82B) Usable Charge: 35min., Full Charge: 40min
(Battery Pack EYFB42, Charger EY0L82B) Usable Charge: 50min., Full Charge: 60min

Assembly Qualifier EYFR02B

The Panasonic EYFR02B is a single tool controller for communicating to Panasonic’s wireless assembly tools. The simple design provides the operator a clear visual and audio feedback, informing the operator of a pass or fail fastening strategy. Connecting the I/O to line stops or a PLC enables additional error proofing capabilities; reducing defects, increasing overall productivity and product quality which leads to a money savings.

Battery pack EYFB30B, EYFB32B

  • 10.8V Li-Ion battery pack
  • EYFB30B: High capacity 3.0Ah
  • EYFB32B: Light weight 2.0Ah

Charger EY0L82B

  • Charger EY0L82B for all 10.8 - 28.8V batteries

Remote control EYFA31B

Protector for Battery EYFB30B / EYFB32B

  • EYFA02-H (gray): for EYFB30B
  • EYFA03-H (gray): for EYFB32B

Protector for Tool EYFLA / EYFMA

  • EYFA01-A (blue)
  • EYFA01-Y (yellow)
  • EYFA01-H (gray)
  • EYFA01-G (green)
